federal-homelab

WS01 STIG remediation

Windows 11 hardening applied through DISA’s published Group Policy Objects, scoped to a Workstations OU, with supplemental policy for the gaps the package leaves open.


Baseline	2026-09-17 — 38.84%, 148 failed rules
Post-remediation	2026-09-22 — 97.11%, 7 failed rules
Benchmark	Microsoft Windows 11 STIG V2R10 / 002.010.018, profile MAC-2 Sensitive, unchanged between scans
Policy source	DISA “DoD Windows 11 STIG” GPO package, v2r8

Method

The DISA GPO package ships Computer and User policy as GPO backups rather than as an installer. Remediation was import, scope, apply, verify — not a one-shot run:

Import both backups into new GPOs on DC01 using a migration table, so the deny-rights entries resolve to real domain principals rather than placeholder text.
Link only to OU=Workstations,OU=Lab,DC=lab,DC=local. Linking at the domain root would apply workstation policy to the domain controller.
Enable loopback processing in Merge mode so the User half reaches whoever logs on to WS01.
Apply the Computer half first, reboot, verify a working desktop, snapshot. Then the User half, reboot, verify, snapshot. Staging the two halves separately means a failure names its own cause.
Rescan, remediate what the package does not cover, rescan again.

The migration table trap

The package’s deny-rights entries contain placeholder principals such as ADD YOUR DOMAIN ADMINS. A migration table maps them to real accounts at import time. The mapping is directional: the placeholder stays in <Source> and the real group goes in a new <Destination> element, replacing the default <DestinationSameAsSource />.

Editing the <Source> value instead produces an import that succeeds silently and writes unresolvable text into User Rights Assignment. The GPO then reports as configured while enforcing nothing. Verification is therefore done against applied policy on the host, not against the GPO report:

secedit /export /areas USER_RIGHTS /cfg "$env:TEMP\ur.inf"
Select-String -Path "$env:TEMP\ur.inf" -Pattern 'SeDeny'

All five deny rights resolved to SIDs — S-1-5-113 (local account), the domain’s -512 and -519 (Domain Admins, Enterprise Admins), and S-1-5-32-546 (Guests). SeDenyInteractiveLogonRight correctly omits S-1-5-113, which is why local console logon still works.

Package version drift

The GPO package is v2r8. The SCAP benchmark scanned against is V2R10 — two releases newer. The package’s own manifest also lists GUIDs that differ from those the archive actually contains, so the GPO backups must be identified by reading each backup.xml rather than trusting the manifest.

The drift is not theoretical. Three rules present in V2R10 have no corresponding setting in the v2r8 package and failed after a clean import and apply:

Rule	STIG ID	Scope	Value the package does not set
V-253425	WN11-CC-000390	Computer	`HKLM\SOFTWARE\Policies\Microsoft\Windows\CloudContent\DisableThirdPartySuggestions`
V-253477	WN11-UC-000015	User	`NoToastApplicationNotificationOnLockScreen`
V-253478	WN11-UC-000020	User	`SaveZoneInformation`

The two user-scope rules were confirmed by controlled comparison: an account that received the User STIG GPO still lacked both values, while an account configured by hand had them. The gap is in the package, not in policy delivery.

These are supplied by a supplemental GPO, Lab - STIG V2R10 Supplement, named so the reason for its existence is readable from the GPMC console.

Scoping and the local-account limitation

Several STIG rules evaluate user-scope policy, and the SCAP content checks them against every user profile’s NTUSER.DAT on the system, not just the scanning user’s. That makes the delivery path for user policy a compliance question rather than a convenience.

Loopback processing in Merge mode is enabled and verified on the host (HKLM\SOFTWARE\Policies\Microsoft\Windows\System\UserPolicyMode = 2). It works — a domain user whose account lives outside the Workstations OU still receives the User STIG GPO, because loopback uses the computer’s OU.

It does not work for local accounts. In Merge mode the Group Policy engine evaluates a GPO’s security filtering against the user, and the default filter is Authenticated Users, a domain group. A local account is not a domain principal and cannot be granted permissions on a domain GPO, so there is no configuration that fixes this.

Consequences:

Consequence	Handling
Local accounts never receive user-scope STIG settings	Values written directly into the local profile’s hive, documented as manual remediation
Scanning as a local administrator would report user-scope failures that reflect the account, not the machine	A domain account, `LAB\stigadmin`, was created and added to WS01’s local Administrators group for scanning
Stale profiles fail user-scope rules permanently	A leftover `LAB\Administrator` profile was removed — the STIG denies Domain Admins interactive logon, so that profile could never be refreshed by policy

stigadmin is a plain domain user with local administrator rights. It is deliberately not a Domain Admin, because the Windows 11 STIG denies Domain Admins and Enterprise Admins every logon type on workstations.

Supplemental policy

Four lab-authored GPOs are linked to the Workstations OU alongside the two DISA GPOs. Link order 1 has highest precedence.

Order	GPO	Purpose
1	`Lab - BitLocker TPM+PIN Override`	Resolves a contradiction in the package’s BitLocker startup options; supplies the recovery-escrow policy the package omits
2	`Lab - Nessus Scan Account`	Grants the scanner service account the access credentialed scanning needs
3	`DoD Windows 11 Computer STIG v2r8`	DISA package
4	`DoD Windows 11 User STIG v2r8`	DISA package
5	`Lab - Workstation Loopback (Merge)`	`UserPolicyMode = 2`
—	`Lab - STIG V2R10 Supplement`	The three V2R10 rules absent from v2r8, Computer and User halves

Lab - Nessus Scan Account grants the scanner its local administrator rights through Group Policy Preferences rather than by hand, so the grant is auditable and reversible by unlinking one GPO. Captured before the STIG GPOs were linked, which is why the Workstations OU shows a single link here:

$Lab - Nessus Scan Account GPO adding LAB\svc-nessus to the local Administrators group$

Defects found in the DISA package

Three issues in the published content, each reproducible:

1. BitLocker startup options are self-contradictory. The package simultaneously permits TPM-only startup, requires a startup PIN, and allows BitLocker without a TPM. Enable-BitLocker rejects the combination with 0x8031005B. Resolved by a scoped override GPO at link order 1 setting UseAdvancedStartup=1, UseTPM=0, UseTPMPIN=1, UseTPMKey=0, UseTPMKeyPIN=0, EnableBDEWithNoTPM=0, MinimumPIN=6.

2. The package enforces pre-boot authentication but omits recovery escrow. With the package alone, Backup-BitLockerKeyProtector fails:

Group policy does not permit the storage of recovery information to Active Directory.

OSRecovery, OSActiveDirectoryBackup, and OSActiveDirectoryInfoToStore are never set. A machine configured strictly from the package encrypts its system volume behind a PIN with no recovery key escrowed anywhere — a single forgotten PIN makes the host unrecoverable. These values are supplied by the override GPO, after which Backup-BitLockerKeyProtector succeeds and the recovery password is verifiable as an msFVE-RecoveryInformation object beneath WS01’s computer account in Active Directory.

3. Version drift, described above.

Account renaming

The Computer STIG GPO renames the built-in accounts itself; no manual step is required. After apply, the SID ending -500 is named X_Admin and -501 is Visitor. Both remain disabled. Verification uses the SID suffix rather than the name, since the name is the thing under test.

Domain-side changes

Workstation account policy comes from the local SAM and is set by the GPO, but domain accounts are governed by the domain. The domain baseline was well short of it:

Setting	Before	After
Minimum password length	7	15
Maximum password age	42 days	60 days
Account lockout threshold	0 — disabled	3
Lockout duration / observation window	10 / 10 min	15 / 15 min

Lockout being disabled domain-wide was the more serious of the two: every domain account, including the scanner service account, permitted unlimited authentication attempts.

Group Policy caps minimum password length at 14 in the UI. The cap is liftable — Relax minimum password length limits, supported on Windows 10/Server version 2004 and later, raises the ceiling to 128 and writes HKLM\SYSTEM\CurrentControlSet\Control\SAM\RelaxMinimumPasswordLengthLimits. Both DC01 and WS01 are well past that version, so 15 characters is enforced rather than recorded as a tooling limitation.

A fine-grained password policy, STIG-Privileged (20 characters, precedence 1), applies to the scanning and service accounts; ordinary domain users fall through to the 15-character domain baseline.

One fine-grained policy defect was found and corrected during this work: two policies existed at the same precedence value, one scoped to Domain Users and one to the privileged group. Active Directory breaks precedence ties by comparing object GUIDs, so the privileged policy was applying to nobody while appearing correctly configured. Get-ADUserResultantPasswordPolicy per account, rather than the policy list, is what surfaced it.

BitLocker

The system volume arrived already 100% encrypted at XTS-AES 128 by Windows’ automatic Device Encryption, with protection off and no key protectors — an encrypted volume whose key sits unprotected on disk, which satisfies nothing.

WN11-00-000030 tests one condition:

SELECT protectionstatus FROM win32_encryptablevolume   →   must equal 1

Reading the OVAL definition rather than the rule title changed the remediation substantially. No decryption or re-encryption was required: adding a recovery password protector and a TPM+PIN protector, then resuming protection, satisfies the rule as a metadata operation rather than a full-volume rewrite. Pre-boot PIN rules (WN11-00-000031/32) were already passing from policy alone.

Add-BitLockerKeyProtector -TpmAndPinProtector fails with 0x80310030 while a bootable ISO is attached to the VM’s virtual optical drive; the drive must be disconnected first.

Residual, self-identified: the volume remains XTS-AES 128 and Used Space Only. No rule in this benchmark tests either, so the scan does not flag it, but used-space-only encryption leaves previously deleted sectors in clear text and DoD prefers 256-bit. Carried in the POA&M as a deferred maintenance action rather than left unstated.

Virtualization-based security

The STIG’s VBS settings apply cleanly but do not take effect on their own. After a clean apply, Win32_DeviceGuard reported SecurityServicesConfigured {1,2} with VirtualizationBasedSecurityStatus = 1 — configured, not running.

Two prerequisites outside Group Policy:

Prerequisite	Action
CPU virtualization extensions exposed to the guest	Enable “Virtualize Intel VT-x/EPT” and IOMMU on the VM
Hyper-V hypervisor present	`Enable-WindowsOptionalFeature -FeatureName Microsoft-Hyper-V-Hypervisor -All` plus `bcdedit /set hypervisorlaunchtype auto`

VBS runs inside Hyper-V’s hypervisor; with the feature absent there is nothing for it to run on. After both, VirtualizationBasedSecurityStatus = 2 and SecurityServicesRunning = {2} — VBS and HVCI active. Credential Guard (1) remains absent, as expected on Pro.

Two side effects, both handled:

Enabling the hypervisor with -All pulls in the full Hyper-V feature family, including the Virtual Machine Management Service, which creates a NAT-capable vEthernet (Default Switch) adapter. A second network interface on a host documented as network-isolated is not acceptable even when it carries no traffic. vmms was stopped and disabled; the adapter disappeared and VBS was unaffected.
Hyper-V setup grants S-1-5-83-0 (NT VIRTUAL MACHINE\Virtual Machines) the create-symbolic-link and log-on-as-a-service rights. That SID does not resolve to a name, so the STIG counts it as an orphaned SID and V-253290 began failing. Removed via secedit export, edit, and reconfigure of the USER_RIGHTS area.

Net effect: enabling VBS closed two rules and opened one, which was then closed.

Incident: shell failure after first BitLocker attempt

Recorded because the response matters more than the fault.

A first BitLocker attempt on an earlier disk image completed encryption at XTS-AES 256 with a TPM+PIN protector. After the next reboot, every interactive logon — one local account and one domain account — reached an authenticated session with no shell: explorer.exe and taskmgr.exe never launched, while sihost.exe and all dependent services ran normally.

Diagnosis was performed remotely over CIM from DC01, since the host had no usable desktop, and eliminated in order: Group Policy (both STIG GPOs unlinked, no change), application control (no AppLocker rule collections present), the Shell and Userinit registry values (both nominal), service state, and memory pressure. The condition persisted in Safe Mode and in Safe Mode with Command Prompt, which placed the fault in the image rather than its configuration.

The host was restored from a snapshot predating the encryption and rebuilt forward. Root cause was not isolated before rollback; the image in question had a prior history of component-store corruption that DISM and SFC could not repair, and a full-volume encryption pass rewrites every sector. The second attempt, on a clean image and without a re-encryption pass, completed and rebooted normally.

Practical conclusions carried forward: stage changes so a failure names its own cause, snapshot before each stage, and bank a measured result before attempting the step already known to be destructive.

Operational effects

Effect	Detail
Pre-boot authentication	A PIN is required at power-on before Windows loads
Account lockout	3 failed attempts locks a domain account for 15 minutes
Passwords	15 characters domain-wide, 20 for privileged and service accounts, 14 for local accounts
Privileged logon	Domain Admins and Enterprise Admins are denied every logon type on WS01. Administration is performed from DC01, and scanning uses purpose-built accounts
Local accounts	Receive no user-scope policy; treated as break-glass only
Group Policy log	Device Guard CSE `{F312195E-3D9D-447A-A3F5-08DFFA24735E}` logs an apply failure at every refresh — expected, and traceable to Credential Guard being unavailable on Pro
Remote Registry	Disabled; enabled only for a credentialed scan window and disabled afterwards

Not remediated

Seven rules remain open — three with no remediation path in this environment, four awaiting certificate content newer than the current distribution tool provides. Listed with reasons in the post-remediation scan summary and carried into the POA&M.
